Dudley Illusion Compact Universal

Compact wall-hung WC pan support frame perfect for bathroom furniture and other confined spaces.

Code323082

Overview

The Dudley Illusion Compact Universal is a high-strength wall-hung WC support frame specifically engineered for restricted spaces. With a slimline width of just 345mm, it provides the ideal solution for narrow bathroom furniture, corners, and other confined domestic or commercial environments. Despite its compact footprint, the frame is constructed from robust square hollow steel and load-tested to 4kN (BS EN 997), ensuring uncompromising stability behind panelling or tiles.

Installation is simplified through exceptional adjustability: legs can be set between 308mm and 395mm for precise WC pan height, while wall and floor brackets rotate through 180° and 360° respectively. Like the standard Universal model, the Compact Universal can be paired with any Dudley concealed cistern, allowing specifiers to design a bespoke, water-efficient system tailored to the most challenging spatial requirements.



Brochure

Features

  • With a width of 345mm the compact universal is perfect for bathroom furniture and other confined spaces
  • Comes with flushbend and WC pan connector clamps
  • Legs adjust to offer WC pan height fixing flexibility
  • Load tested to 4kN to ensure compliance with BS EN 997 when fitted with a wall-hung pan
  • Wall and floor fixing brackets can be fixed through 180 degrees and 360 degrees respectively to provide further flexibility
  • Strong steel square hollow construction
  • 5L & 4L mono flush is achievable
  • 5 working day dispatch

For Specifiers

Better By Design

The Dudley Illusion range offers specifiers a proven, versatile solution for wall-hung sanitaryware installations, delivering reliable performance behind panelling, tiles, and within fitted bathroom furniture.

Whether for new builds or bathroom refurbishments, Illusion frames provide simple, hassle-free installation while offering the flexibility to design optimal layouts. Their robust, engineered construction ensures stability and compliance with industry standards, giving confidence in both domestic and commercial applications.

The range’s unique design allows unrivalled adaptability in positioning and integration, supporting bespoke water-saving strategies and seamless integration with modern architectural and interior design requirements. Illusion frames empower specifiers to balance functionality, aesthetics, and sustainability without compromise.
